D-Link DIR-842V2 User Manual

5
ENGLISH
FREQUENTLY ASKED QUESTIONS
Why can’t I access the web-based conguration utility?
Verify that http://dlinkrouter.local./ is correctly entered into the browser.
At this stage, you are not connecting to a website, nor do you have to be
connected to the Internet. The device has the utility built-in to a ROM chip in
the device itself. Your computer must be connected to the router’s network
and in the same IP subnet to connect to the web-based utility.
Why can’t I access the Internet?
Verify that your router is working by rebooting the router. If you still can not
connect to the Internet, contact your Internet service provider.
What do I do if I forgot my device password / my wireless network
password?
If you forgot your password, you must reset your router. This process will
change all your settings back to the factory defaults.
How do I restore the router to its factory default settings?
Locate the reset button on the rear panel of the unit. With the router powered
on, use a paper clip to hold the button down for 10 seconds. Release the
button and the router will go through its reboot process.
For technical support, product documentation and other information,
please visit our website.
https://eu.dlink.com/support

D-Link DIR-842V2 Specifications

General

Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN
Indication light	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
DSL WAN	No
WAN connection type	RJ-45
Ethernet LAN (RJ-45) ports	5
Antennas quantity	4
Antenna gain level (max)	5 dBi
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Browser supported	Microsoft Internet Explorer 10+, Microsoft Edge 20.10240+, Firefox 44, Chrome 48+, Safari 8, Opera 35
Security algorithms	128-bit AES, WPA3, WPS
Number of products included	1 pc(s)
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	132.5 mm
Width	181 mm
Height	47.71 mm
Weight	304.8 g
