4D-Link DIR-859 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and video game consoles.
2 Reset Button
Press and hold the reset button with a paper clip for six seconds to reset the router to the factory default settings. The
button is located on the bottom of the router.
3 Internet Port Connect your broadband modem to this port using an Ethernet cable.
4 Power Port Connect the supplied power adapter to this port.
5 Power Button Press the power button to power the router on and o.
6 WPS Button
Press to start the WPS process. The WPS LED will blink during the process. The light will turn solid green when successfully
connecting to a device.
1
3 4
5
62
