D-Link DIR-860L

8D-Link DIR-860L User Manual
Section 2 - Installation
1. Turn o and unplug your DSL or Cable modem. This is required.
Connect to your Network
Modem
2. Connect an Ethernet cable from the Internet port of the router to the Ethernet port on your DSL or Cable modem.
12V
2A
USB
WPS
1
2
3
LAN
4
INTERNET
POWER
Modem
DIR-860L
Ethernet Port
Ethernet Cable
Internet Port (yellow)
