D-Link DIR-867 User Manual

109D-Link DIR-867 User Manual
Section 6- Connecting a Wireless Client
When connecting to the DIR-867 wirelessly for the rst time, you will need to input the wireless network name (SSID) and
Wi-Fi password (security key) of the device you are connecting to. If your product has a Wi-Fi conguration card, you can
nd the default network name and Wi-Fi password here. Otherwise refer to the product label for the default Wi-Fi network
SSID and password, or enter the Wi-Fi credentials set during the product conguration.
To join an existing network, locate the wireless network icon in the taskbar,
next to the time display and click on it.
Wireless Icon
Clicking on this icon will display a list of wireless networks which are within
range of your computer. Select the desired network by clicking on the SSID.
Windows® 10

D-Link DIR-867 Specifications

General

Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WLAN
Certification	FCC, IC
Processor cores	2
Built-in processor	Yes
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11u, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
WLAN data transfer rate (first band)	450 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
Antennas quantity	4
SIM card slot	No
WAN connection type	RJ-45
Number of products included	1 pc(s)

Weight and Dimensions

Depth	183.7 mm
Width	258.8 mm
Height	49.2 mm
Weight	576 g
