DIR-879 Quick Installation Guide
Conguring LAN Ports for IPTV/VoIP
1. On the IPTV page, select the Is an STB connected to the device
checkbox.
2. Select a free LAN port for connecting your set-top box.
3. If the IPTV service is provided via a VLAN channel, select the Use
VLAN ID checkbox and fill in the VLAN ID field.
4. Click the NEXT button.
5. On the VoIP page, select the In an IP phone connected to the
device checkbox.
6. Select a free LAN port for connecting your IP phone.
7. If the VoIP services provided via a VLAN channel, select the Use VLAN
ID checkbox and fill in the VLAN ID field.
8. Click the NEXT button.
28
