D-Link DIR-890L Quick Install Guide

7
5
Plug the power adapter into your router and connect to an available
power outlet or surge protector. If the Power LED does not light up, press
the Power button on the back of the router.
6
After the router has powered up, verify that the Power (white) and Internet
(white or orange) LEDs are both lit. Proceed with router conguration.
Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari)
and enter http://dlinkrouter.local./ or the IP address of the router
(http://192.168.0.1).
1
1 2 3 4
USB 2.0USB 3.0
POWER
WSP
DCN IN
12V
SA
...
-
RESET
INTERNET
Modem
DIR-890L
Conguration
There are two ways to congure your router:
A. Web Browser - Use a web browser from your computer.
B. QRS Mobile app - Use a mobile device with the D-Link QRS Mobile app.
Refer to the QRS Mobile Setup section for more information.
A. Web Browser Conguration

D-Link DIR-890L Specifications

General

VPN support	PPTP/L2TP/IPsec
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	3200 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Input current	5 A
Rack mounting	No
Frequency band	2.4 & 5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
DHCP client	-
Antennas quantity	6
Security algorithms	WPA, WPA2, WPS
Product type	Tabletop router
Product color	Red
Certification	IC\\r CE\\r Wi-Fi Certified\\r FCC
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	387 mm
Width	247.3 mm
Height	119.5 mm
Weight	- g
