4D-Link DIR-905L User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
INTERNET
A solid light indicates connection on
the WAN port. This LED blinks during
data transmission.
WLAN LED
A solid light indicates that the wireless
segment is ready. This LED blinks during
wireless data transmission.
Local Network LEDs
A solid light indicates a connection to an
Ethernet-enabled computer on ports 1-4. This
LED blinks during data transmission.
Power LED
A solid light indicates a proper
connection to the power supply.
