4D-Link Media Converter Series
Section 1 - Product Overview
Hardware Overview
Front Panel View
1000 Mbps Media Converter Series10/100 Mbps Media Converter Series
2 31
1 Tx and Rx SC ber optic port
2 Indicator LEDs
3 10/100BASE-T Ethernet port
2 31
1
LC ber optic port (1910R/T)
SC ber optic port (700SC/810SC)
2 Indicator LEDs
3 1000BASE-T Ethernet port
