DNS-1560-04 Quick Installation Guide
This installation guide provides basic instructions for installing the DNS-1560-04 on your
network. For additional information about how to use the DNS-1560-04, please see the User’s
Manual which is available on the CD included in this package or from the D-Link support
website.
Installation Steps:
1. Verify the package contents against the list below
2. Hardware Overview
3. Hardware Installation
4. Conguration with Wizard
Package Contents
 D-Link DNS-1560-04
 HDD trays
 Quick Installation Guide
 Power Cords x 2
If any of the above items are missing, please contact your reseller.
2. Hardware Overview
Front Panel
Item Function Description
1 Ethernet Status LED LED – Blinking amber: Accessing data.
2 Status LED Blinking amber: System error.
3 Power Button Blue: Power on.
4 Key hole Disk drive key hole.
5 Disk Status LED LED displaying disk status.
1
2
3
4
5
 Rail kit (x1 set)
 CD-ROM with Manual and Software
 Keys, screws for drives and rail kit
(x1 packet)

D-Link DNS-1560-04 Specifications

General

Brand	D-Link
Model	DNS-1560-04
Category	Network Hardware
Language	English
