D-Link DNS-1560-04 Quick Installation Guide
7
ENGLISH
To install the DNS-1560-04 in a rack enclosure read the following instructions:
1. Push the release tab pictured below and remove the inner sleeve from the outer sleeve.
2. Attach the inner sleeve to the DNS-1560-04 with the screws provided.
3.4 Installing the DNS-1560-04 in a Rack Enclosure
3. Using the screws supplied, attach the outer sleeve to the racking system.
Inner Sleeve
Inner Sleeve
Outer sleeve
Release Tab
