5 D-Link DNS-323 Quick Install Guide
Hardware Installation
Hardware Installation
1. Accessthedrivebaysbyslidingthefaceplateupuntilitunlatches
fromthedevice.
2. Oncethefaceplateisunlatched,pullitoffofthedevice,exposing
thedrivebays.
3. Inserta 3.5” SATA hard drive into eachavailable drivebay.
Makesuretoalignthedriveconnectorstotheendpointsinthe
DNS-323.Gentlypushthedriveinuntilitconnects.
Note: If only one 3.5” SATA drive
is available place this drive in the
LEFT bay with the opening (front) of
the DNS-323 facing you.
