PRODUCT
SET-UP
HARDWARE OVERVIEW
The DLink DPN101G is a mini GPON ONT that uses a GPON link to deliver highspeed
broadband. It’s plugandplay capabilities coupled with a small form factor make it ideal
for residential applications. With bridging for Tripleplay, users can use dataintensive
Internet devices simultaneously without experiencing network delay. To give users better
access to the Internet, the 10/100/1000 Mbps Ethernet is equipped with this GPON
residential gateway. Supporting IEEE 802.3az, the DPN101G delivers energy efficient
Ethernet to your home.
DPN101G INSTALLATION
1. Remove the rubber stopper from the GPON port on the DPN101G.
2. Connect fiber by feeding the fiber optic connector into the back of the GPON port.
Ensure the center conductor of the fiber is inserted directly into the center of the
PON connector. Secure the fiber by carefully pushing the fiber connector onto the
PON connector until tight. Be careful not to overtighten the connector or you may
damage either the connector or the GPON port.
3. Connect the DPN101G to a 10/100/1000 Mbps network by using a RJ45 Ethernet
cable.
4. Connect the AC adapter to the GPON ONT by inserting the connector into the side
of the GPON ONT.
Warning: Invisible LASER radiation may be emitted from the end of the fiber and/or from
the DPN101G ONT. Take all necessary precautions to avoid unnecessary exposure to
this radiation.
