In this section, the following parameters can be configured:
Tunnel Name: Enter the tunnel name here.
Mechanism: Select the tunnel mechanism option here. 6RD is the only option
available.
Associated WAN Interface: Select the WAN interface that will be associated with
this entry here.
Associated LAN Interface: Select the LAN interface that will be associated with
this entry here. Also select whether this interface will obtain the IPv4 mask
length, 6rd prefix, and border relay IPv4 address information manually, by
selecting Manual, or automatically, by selecting Automatic.
Remote IPv6 Address: After selecting Manual, enter the remote IPv6 address
here.
Click the Apply/Save button to accept the changes made.
