D-Link DSL-225 User Manual

D-Link DSL-225 11N VDSL2 Router User Manual
Product Overview
Page 6
Rear Panel
Number
Description
1
VDSL Port - Use the DSL cable to connect to your telephone line (RJ-11 port).
2
Ethernet Ports - Use the Ethernet ports to connect the router to your Ethernet
LAN or Ethernet devices.
3
Reset Button - Press and hold the button 5 seconds to restore the device to its
original factory default settings.
4
Power Button - Push in to power-on the router. Push again to power-off the
router.
5
Power Receptor - Receptor for the supplied power adapter.
6
Wall-Mount Slots – Wall-mount slots to mount the router on the wall.

D-Link DSL-225 Specifications

General

Brand	D-Link
Model	DSL-225
Category	Network Router
Language	English
