In this section we can configure the following parameters.
Enable Wireless: Tick this option to enable the wireless feature on this router.
Enable Wireless Hotspot 2.0: Check this option to enable wireless hotspot 2.0.
Hide Access Point: Here we can choose to hide the Wireless SSID by selecting
clicking the checkbox.
Clients Isolation: Click the checkbox to enable.
Disable WMM Advertise: Click the checkbox to enable the Wi-Fi Multimedia
(WMM) advertisement feature
Enable Wireless Multicast Forwarding (WMF): Click the checkbox to enable the
Wireless Multimedia Forwarding (WMF) feature.
SSID: Enter the Wireless name (SSID) here. This name will be available when
wireless clients scan for available wireless networks. However, when the Hide
Access Point option is enabled, this name will not be visible to wireless clients
BBSID: The ID is automatically set.
Country: This parameter will display the country information.
Country RegRev: Enter the country registration number here.
Max Clients: Set the number of users that can access the device.
Wireless – Guest/Virtual Access Points: Click the checkbox to enable one of the
guest Access Points
Enabled – Select this option to enable the Guest/Virtual Access Point option for the
entry specified.
SSID – When available enter the SSID for the Virtual Access Point (VAP) here.
Hidden – Select this option to hide the SSID of the selected VAP.
Isolate Clients – Select this option to isolate the wireless clients of the selected VAP from the rest of the network.
Enable HSPOT – Set the hotspot value per SSID
Max Clients – Enter the maximum number of wireless clients that can connect to the select VAP.
Click the Apply/Save button to accept the changes made.
