D-Link DSL-225 User Manual

D-Link DSL-225 11N VDSL2 Router User Manual
Web User Interface Configuration
Page 75
In this section we can configure the MAC filtering rule.
Parameters available for configuration are:
Protocol Type: Select the protocol type option that will be associated with this rule.
Options to choose from are PPPoE, IPv4, IPv6, IPX, and IGMP.
Destination MAC Address: Enter the destination MAC address used here.
Source MAC Address: Enter the source MAC address used here.
Frame Direction: Select the Frame Direction from the drop-down menu. Select
between LAN /WAN, WAN/LAN, or LAN to WAN.
WAN Interface: Select the WAN interface that will be associated with this rule here.
Click the Save/Apply button to accept the changes made.
After the rule was added, it will be displayed in this section.
