DSL-245GR Quick Installation Guide
SPECIFICATIONS
*
Hardware
Processor
· RTL8685PB (1GHz)
RAM
· 128MB, DDR2, built in processor
Flash
· 16MB, SPI
Interfaces
· 1 RJ-11 DSL port
· 4 10/100/1000BASE-T LAN ports
· USB 2.0 port
LEDs
· POWER
· DSL
· INTERNET
· 4 LAN LEDs
· 2.4G WLAN
· 5G WLAN
· WPS
· USB
Buttons
· ON/OFF button to power on/power off
· RESET button to restore factory default settings
· WPS button to set up wireless connection
· WIFI button to enable/disable wireless network
Antenna
· Two external non-detachable antennas for 2.4GHz band
(5dBi gain)
· Two external non-detachable antennas for 5GHz band
(5dBi gain)
MIMO
· 2 x 2
Power connector
· Power input connector (DC)
* The device features are subject to change without notice. For the latest versions of the
firmware and relevant documentation, visit www.dlink.ru.
43
