D-Link DSL-2520U Quick Installation Guide

DSL-2520U Quick Installation Guide
6. For the PPPoE and PPPoA connection types, enter authorization data
provided by your ISP in the PPP section (the username (login) in the
Username field and the password in the Password and Password
confirmation fields). If these data have not been provided by your ISP,
select the Without authorization checkbox.
7. For the IPoA and Static IP connection types, fill in the IP Address,
Netmask, and Gateway IP address fields in the IP section.
8. Deselect the NAT checkbox in the Miscellaneous section if your ISP
requires you to disable the network address translation function.
9. Click the Save button.
12

D-Link DSL-2520U Specifications

Data Transfer Rates

ADSL full rate downstream	up to 8 Mbps
ADSL full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL2 full rate downstream	up to 24 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface	RJ-45 port for 10/100BASE-T Ethernet
USB interface	USB port Type B connector, USB 1.1 Specification
