D-Link DSL-G256DG VDSL Router User Manual
Web User Interface Configuration Page 83
In this section we can configure Port Forwarding rules.
Use Interface: Select an existing interface from the list that will be associated with
this rule.
Select a Service: Select a service from the list. These pre-defined services will
contain all the parameters needed to create a successful rule.
Custom Service: If the service is not located in the list, we can create our own
service. Enter the service name for the rule here.
Server IP Address: Enter the server IP address here.
External Port Start: Enter the external starting port number here.
External Port End: Enter the external ending port number here.
Protocol: Select the appropriate protocol used here. Options to choose from are
TCP/UDP, TCP, and UDP.
Internal Port Start: Enter the internal starting port number here.
Internal Port End: Enter the internal ending port number here.
Click the Apply/Save button to accept the changes made.
Click the Cancel button to discard the changes made and return to the main page.
