D-Link DWL-3200AP - AirPremier - Wireless Access Point

109
DWL-3200AP User’s Manual
D-Link Systems, Inc.
Technical Specifications
For 802.11g:
• 400mW (26dBm)
• 200mW (23dBm)
• 100mW (20dBm)
• 63mW (18dBm)
• 32mW (15dBm)
• 16mW (12dBm)
• 3mW (5dBm)
Receiver Sensitivity
For 802.11b:
• 1Mbps: -94dBm
• 2Mbps: -90dBm
• 5.5Mbps: -89dBm
• 11Mbps: -85dBm
For 802.11g:
• 1Mbps: -94dBm
• 2Mbps: -90dBm
• 5.5Mbps: -89dBm
• 6Mbps: -90dBm
• 9Mbps: -84dBm
• 11Mbps: -85dBm
• 12Mbps: -82dBm
• 18Mbps: -80dBm
• 24Mbps: -77dBm
• 36Mbps: -73dBm
• 48Mbps: -72dBm
• 54Mbps: -72dBm
LEDs
• Power
• LAN
• 802.11b/g
Temperature
• Operating: -40ºF to 140ºF (-40ºC to 60ºC)
• Storing: -40ºF to 149ºF (-40ºC to 65ºC)
Humidity
• Operating: 10%~90% (non-condensing)
• Storing: 5%~95% (non-condensing)
Certifications
• FCC
• WiFi
Dimensions
• L = 10.93 inches (277.7mm)
• W = 6.10 inches (155mm)
• H = 1.77 inches (45mm)
Warranty
• 1 Year
