24
DWL-3200AP User’s Manual
D-Link Systems, Inc.
Using the Configuration Menu
Advanced > Performance
Wireless Band:
Frequency:
Channel:
Data Rate:*
Beacon Interval:
IEEE 802.11g
The frequency is 2.437GHz for channel 6.
The default channel is 6.
The Data Rates are Auto, 1Mbps, 2Mbps, 5.5Mbps, 6Mbps, 9Mbps,
11Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps.
Beacons are packets sent by an access point to synchronize a
network. Specify a beacon interval value. The default (100) is
recommended.
*Maximum wireless signal rate derived from IEEE Standard 802.11g and IEEE Standard 802.11b specifications. Actual data
throughput will vary. Network conditions and environmental factors lower actual data throughput rate.
