Hardware Overview
This is the connector that
fits into the PCI slot on your
computer’s motherboard.
32-bit connector
Used to wirelessly connect
to WiFi networks.
Smart Antenna
Indicates that the adapter
is properly installed when
the computer is on and
blinks when data is being
transmitted.
Link/Activity LED
Hardware Overview
3
