D-Link GO-SW-8G Quick Installation Guide

GO-SW-5G & 8G
3
ENGLISH
PRODUCT SETUP
SWITCH SET-UP
Step 1
Connecting the power adapter
Plug the power adapter into a free wall socket, then plug the
other end of the power adapter cable into the power port of the
GO-SW-5G & 8G . The power LED will light up, conrming that the
device is powered up successfully.
Step 2
Connecting your Network Devices
Use a LAN cable to connect your network device to one of the 5
ports on the GO-SW-5G/ or 8 ports on the GO-SW-8G.
Step 3
Determine that the Switch is Powered On
The Power LED indicator light is green when the Switch is receiving
power; otherwise, it is off.
Determine that the Network Devices are Connected
The Link/Act LED indicator light is green when the port is connected to a
device.
The green indicator blinks as data is transmitted or received.
RouterInternet
LED

D-Link GO-SW-8G Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Packet buffer memory	0.125 MB
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 20, 100, 200, 1000, 2000 Mbps
10G support	-
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Switch type	Unmanaged
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	8
Power consumption (typical)	3.9 W
Certification	FCC, ICES, CE, C-tick, VCCI, cUL/UL, CCC, LVD
Product color	White
Mean time between failures (MTBF)	412433 h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Connectivity technology	Wired

Weight and Dimensions

Depth	68.5 mm
Width	128 mm
Height	25.4 mm
Weight	195 g
