DIR-X1860 Quick Installation Guide
SPECIFICATIONS
*
Hardware
Processor
· MT7621AT (880MHz, dual core)
RAM
· 256MB, DDR3L SDRAM
Flash
· 128MB, NAND
Interfaces
· 10/100/1000BASE-T WAN port
· 3 10/100/1000BASE-T LAN ports
LEDs
· Power
· Internet
· WLAN 2.4G
· WLAN 5G
Buttons
· POWER button to power on/power off
· RESET button to restore factory default settings
· WPS button to set up wireless connection and
enable/disable wireless network
2
Antenna
· Two external non-detachable antennas for 2.4GHz band
(5dBi gain)
· Two external non-detachable antennas for 5GHz band
(5dBi gain)
MIMO
· 2 x 2, MU-MIMO
Power connector
· Power input connector (DC)
* The device features are subject to change without notice. For the latest versions of the
firmware and relevant documentation, visit www.dlink.ru.
2 Disabling/enabling the Wi-Fi network via the hardware button will be implemented in
future software versions.
