Section 1 - Product Overview
Hardware Overview
LEDs
Ethernet LED
• Solid. The Ethernet port is linked.
• O. There is no Ethernet connection.
Powerline LED
• Solid. The device is connected to a PowerLine network.
• Off. The device has not found any other compatible
PowerLine devices using the same encryption key.
The color indicates the PowerLine link rate:
• Green. The PowerLine link rate is excellent.
• Amber. The PowerLine link rate is good.
• Red. The PowerLine link rate is fair.
Power LED
• Solid. The device is receiving electrical power.
• Blinking. The device is setting itself up after reset or
simple connect button was pressed.
• O. The device is not receiving electrical power.
