Weighing Mode Setting
Weighing Mode Selection
F21
●
1 Limit Mode (Weighing mode 1)
2 Packer Mode (Weighing mode 2)
3 Checker 1 mode (Weighing mode 3, When stable)
4 Checker 2 mode (Weighing mode 4, Level meter type)
Relay output Mode(Each weighing Mode)
Relay Output Out 1 Out 2 Out 3 Out 4
1 Limit SP1(Low) SP2(High) Finish Empty
2 Packer SP1(Low) SP2(High) Finish Empty
3 Checker 1 SP1(Low) SP2(High) OK Empty
4 Checker 2 SP1 SP2 SP3 Empy
