Dacor ELECTRONICS - Page 26

Elecronic Diagnostics Page 26
Check across 2
and 5 for bake
from the 16 pt
connection of the
main wire
harness for 22-24
VDC and 1 and 11
fo
r the cooling
fan.
Check across 2 and 5 for
22-24 VDC from the 16 pin
connection of the main
wire harness of the ERC for
the bake coil.
Preheat
Self-Clean
Gas Ranges
