Product Dimensions
de s i g n sp eCifiCa T i o ns
3/8" (10mm)ø
Both sides
6" x 6" (152mm x 152mm)
Utility Cutout
25"
(635mm)
12" (305mm) Min.
to combustibles
above the countertop
surface
4 1/4"
(108mm)
21"
(533mm)
2" (51mm)
EOG30 - 21" (533mm)
EOG36/52 - 28" (711mm)
EOSB162 & EOG303/36/52
Cutout Dimensions Top View
9 1/8"
(232mm)
23"
(584mm)
26 3/8"
(670mm)
27 1/8"
(689mm)
30"
(762mm)
23"
(584mm)
EOG303 Overall Dimensions
9 1/8"
(232mm)
23"
(584mm)
26 3/8"
(670mm)
27 1/8"
(689mm)
36"
(914mm)
23"
(584mm)
EOG36 Overall Dimensions
8 3/4"
(222mm)
23"
(584mm)
26 3/8"
(670mm)
27 1/8"
(689mm)
16"
(406mm)
EOSB162 Overall Dimensions
8 3/4"
(222mm)
23"
(584mm)
26 3/8"
(670mm)
27 1/8"
(689mm)
52"
(1321mm)
23"
(584mm)
EOG52 Overall Dimensions
