Product Specifications
Product Dimensions - ERV36-ER and ERV48-ER
30 1/4"
(76.8 cm)
to
37 1/4"
(94.6 cm)
10"
(25.4 cm)
30"
(76.2 cm)
18 5/8”
(47.3 cm)
5/16” (8 mm)
thick stiffener
across back
3 3/4"
(9.5 cm)
1"
(2.5 cm)
28" 3 prong
grounded
power cord
Vent shown
in raised
position
Product
data label
Motor
cover
Front of unit
6"
(15.2 cm)
2 9/16"
(6.5 cm)
2 1/2"
(6.4 cm)
1 15/16"
(4.9 cm)
B
A
Adjustable
anchor legs
2 13/16"
(7.1 cm)
1/4"
(6 mm)
Top cap with
vent down
Tolerances: ±1/16”, (±1.6 mm) unless otherwise stated
Model
Number
Top Cap
Width (A)
Chassis
Width (B)
ERV36-ER 36” (91.4 cm) 33 3/8” (84.8 cm)
ERV48-ER 48” (121.9 cm) 43 3/8” (110.2 cm)
See page 9 for
exhaust locations and
dimensions
*
* Maximum height of
downdraft vent must not
exceed maximum speci-
fied counter height for
cooking appliance. See
installation instructions for
cooking appliance.
