Please read all instructions thoroughly before installing the over the range microwave oven/hood system. Two
people are recommended to install this product.
If a new electrical outlet is required, its installation should be completed by a qualified electrician before the over
the range microwave oven/hood system is installed. See 3 ELECTRICAL GROUNDING INSTRUCTIONS on page 2.
This microwave oven/hood requires a mounting space on
a wall as shown in Figure 1. It is designed to be used with
standard 12-inch wall cabinets.
Consult the installation instructions for the range or cooktop
being installed for additional and/or superseding minimum
distance requirements.
2 WALL CONSTRUCTION
Figure 1
At least 2"
15.5"
30"
Backsplash
12"
66" or more
from floor
30" or more from
cooking surface
Before You Begin...
1 MOUNTING SPACE
To Next Page
