Dacor RV30 - Product Specifications; Product Dimensions

3
Product Dimensions
Product Specifications
26 3/4"
(679 mm)
1/2” (13 mm)
thick stiffener
across back
4 5/8" (117 mm)
9 7/8” (251 mm)
with CABP3
blower installed
Vent shown
in raised
position
Product
data label
2 5/16"
(59 mm)
9/16"
(14 mm)
3 1/8"
(79 mm)
2"
(51 mm)
B
A
Adjustable
anchor legs
1 13/16"
(46 mm)
1 15/16"
(49 mm)
3/16"
(5 mm)
Top cap with
vent down
7" (178 mm)
7 1/2" (191 mm)
Front View
15/16" (24 mm)
28"
(711 mm)
to
34"
(864 mm)
Tolerances: ±1/16” (±1.6 mm) unless otherwise stated
Model
Number
A - Top Cap
Width
B - Chassis
Width
RV30 30” (762 mm) 27 3/8” (695 mm)
RV36 36” (914 mm) 33 3/8” (848 mm)
RV46 46” (1168 mm) 43 3/8” (1102 mm)
See page 8 for exhaust
locations and dimensions
