DAELIM CORDI User Manual

39
[REAR WHEEL REMOVAL]
① Set vehicle on main stand in upright
position on level ground.
② Loosen the rear brake adjuster nut.
③ Remove the muffler.
④ Loosen the rear wheel axle nut.
⑤ Remove the lock washer and the rear
wheel.
⑥ Install in the reverse order of removal.
REAR AXLE NUT TORQUE
: 11kgf
··
m
●Erect main stand and place vehicle
in up right position on level ground.
●Check the spring for damage or loss
of tension and the side stand
assembly
for freedom of movement.
●For model with a side stand switch,
check the side stand ignition cut off
system;
① Put the side stand up.
② Start the engine.
③ Lower the side stand. The engine
should stop as you put the side
stand down.
●If the side stand system does not
operate as described, inspect it in the
closest authorized repair center.
SIDE STAND INSPECTION
ADJUSTNUT
MUFFLER
AXLENUT
REARBRAKEARM
WARNING
●If a torque wrench was not used for
installation, see your authorized
dealer as soon as possible to verify
proper assembly.
Improper assembly may lead to loss
of braking capacity.
SIDESTANDSWITCH
SIDESTANDSPRING
