DAEWOO ELECTRONICS E1032D - 3 Product Function

Service Manual
3
Service Manual
3. Product Function
VIDEO INPUT TV
Receiving Range 48.25MHz-863.25MHz
Input Impedance 75
Video System PAL/SECAM
Sound System B/G,D/K/I
Sound System NICAM/A2,
Max storage channels 200CH
PC-RGB
Format Up to 1920×1080@60Hz
CVBS
Video System PAL/NTSC/SECAM
Video Level 1.0 Vp-p ±5%
S-Video
S-Y:0.714Vp-p+/-5% S-C:0.286Vp-p+/-5%
HDMI
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Component
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
SCART (EUR)
CVBS & RGB (CANAL+ is not supported) ,
AUDIO INPUT PC-RGB
Earphone Input 0.2 – 2.0 Vrms
CVBS
L/R RCA Input 0.2 – 2.0 Vrms
S-Video
Component
AUDIO OUTPUT Frequency Response
100Hz - 15000Hz @±3dB (1KHz 0dB reference signal)
AUDIO OUTPUT Max Output Power
2×8W,THD+N<10%@1KHz (Power Supply:24V, Audio Input: 0.5VRMS)
COMB FILTER
3D
DEINTERLACE
3D
WEAK SIGNAL ENHANCEMENT
YES
NOISE REDUCTION
YES
KEY FUNCTION
MENU, CH+, CH-, VOL+, VOL-, INPUT, POWER
INPUT TV
1 IEC-Connector 75
PC-RGB
1 D-SUB 15Pin terminal(blue)
CVBS
1 RCA terminal(yellow)
S-Video
0 S-Video terminal(black)
Component
2*3 RCA terminals(green, blue, red)
HDMI
3 HDMI terminal
SCART (EUR)
0 full SCART terminal
CVBS Audio
2 RCA terminals(red, white)
S-Video Audio
Component Audio
PC-RGB Audio
1 Earphone terminal(black)
USB
1 USB Slot(vertical)
OUTPUT Earphone
1 Earphone terminal(black)
Coaxial(optional)
1 RCA terminal(orange)
AV Out
0 RCA terminals(yellow, red, white)
