DAEWOO ELECTRONICS E1032D - 5 Chassis Layout and Overall Wiring Diagrams; E1032 D (EM32 A1 B ) Major Part Bom; E1042 D (EM42 A1 BF ) Major Part Bom

Service Manual
6
Service Manual
5. Chassis Layout and Overall Wiring Diagrams
5.1 E1032D (EM32A1B ) Major Part Bom
No
Parent Nombel Material Description
1 7.11.SP407504A0LK1 B/T Adapter(Power Boadr) LEKE,LK-SP407504A(自带麦拉片,麦拉片已贴好双面胶
单独配送),加长板,低功耗,ROHS
2 7.15.TMSD6M1810CV5 Main Board CVT,T.MS6M181.6A, (Asia,贴6E181芯片，带
TXT/NICAM),ROHS
3 1.18.LED320SA0AN12 LED Panel SAMSUNG,LTA320AN12,1366*768,LED, ROHS
4 1.22.01SJ1050481423 Speaker SJX SJ-11050401A,8 Ω 10 W ,长距离软胶垫,ROHS
5 7.05.E1032E0000001 Key Board E1032E,ROHS
6 7.04.E1032E0000001 IR LED Board E1032E,ROHS
5.2 E1042D (EM42A1BF ) Major Part Bom
No
Parent Nombel Material Description
1 7.11.SP16002A00LK1 B/T Adapter(Power Boadr) LEKE,LK-SP416002A(自带麦拉片,麦拉片贴好双面胶单
独配送),低功耗，ROHS
2 7.15.TMSD6M1810CV5 Main Board CVT,T.MS6M181.6A, (Asia,贴6E181芯片，带
TXT/NICAM),ROHS
3 1.18.LED420CMLS2C7 LED Panel CMO,V420H2-LS2-C7,1920*1080,ROHS
4 1.22.01SJ1050481423 Speaker SJX SJ-11050401A,8 Ω 10 W ,长距离软胶垫,ROHS
5 7.05.E1032E0000001 Key Board E1032E,ROHS
6 7.04.E1032E0000001 IR LED Board E1032E,ROHS
