30
12. Top Panel of Refrigerator
1. Remove screws.
13. Return Duct Cover
1. Hold light bulb cover to pull it down.
2. Turn light bulb counterclockwise to pull it out.
Be careful not to break hooks while removing the cover.
3. Remove left Lamp Socket and right R-Sensor Housing by
pulling them out smoothly.
4. Pull down left and right body of Duct.
5. Pull forward the Duct.
DISASSEMBLY AND ASSEMBLY
