DISASSEMBLY AND ASSEMBLY
1. Freezer & Refrigerator Doors
1. Insert flat type (-) screw driver between Hinge Cover
and Cabinet surface to remove the Cover.
(Be careful not to break the hooks of Cover and not
to damage the Cabinet surface.)
2. Remove 4 bolts with 10mm wrench.
3. Disconnect Connector Housing.
4. Lift F-Door a little to remove it.
5.Unfasten Hinge Pin with 6mm wrench.
6. Lift R-Door up a little to remove it.
