NO PART CODE PART NAME DESCRIPTION Q'TY
A00 DOOR AS
3511723710 KOG-3Q17 1
B00 CONTROL-PANEL AS
3516730620 KOG-3Q17 1
C00 3513302700 INSULATOR HEATER AS KOG-37150S 1
F01 3510805300 CABINET AS KOR-61150S 1
F02 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 3
F03 3516109510 CAVITY AS KOG-37150S 1
3516109610 CAVITY JOINT AS KOG-37150S 1
F04 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 1
F05 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 2
F06 35113A5QJ5 CORD POWER AS 3X1.5 80X80 120-RTML 1.4M 1
F07 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 1
F08 7121300611 SCREW TAPPING T2S PAN 3X6 MFZN 1
F09 3518904500 THERMOSTAT OFF:100 ON:90 HN #187 1
F10 7S627W50X1 NUT HEX NUT FLANGE M5X0.8P MFZN 1
F11 3518606100 NOISE-FILTER DWLF-M13 1
F12 7121402511 SCREW TAPPING T2S PAN 4X25 MFZN 2
F13 3963512310 MOTOR SHADED POLE 230V 20W MW10CA-M02 1
F14 3512517000 GUIDE WIND PP 1
F15 3511800300 FAN PP+30%GLASS 1
F16 3518003700 MAGNETRON 2M218JFL 1
F17 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO 1
F18 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1
F19 3513003200 HOLDER HV CAPACITOR SECC T0.6 1
F20 3518302200 CAPACITOR HV 2100VAC 0.98UF #187 1
F21 3518400400 DIODE HV HVR-1X-3AB 12KV #187 1
F22 3518701100 FUSE HV 5KV 0.55A HV-41A55-02 1
F23 3518113790 TRANS HV DW-R80S0-63TA 1
F24 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 4
F25 3510311700 BASE SBHG T0.7 1
F26 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 5
F27 3512100900 FOOT PP DASF-130 2
F28 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1
F29 3515201101 STOPPER HINGE *U SCP-1 T2.5 1
F30 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 1
F31 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 1
F32 3518570400 SWITCH S/A RELAY DWSR-1 1
