DAEWOO ELECTRONICS KOR-4125 - Disassembly and Assembly

14
DISASSEMBLY AND ASSEMBLY
1. To remove cabinet
Remove three screws on cabinet back.
2. To remove door assembly.
1) Remove two screws ¤ Which secure the stopper
hinge top.
2) Remove the stopper hinge top ¤Ł and door
assembly ¤Øfrom top plate of cavity.
3) Remove the stopper hinge top ¤Ł from door
assembly.
4) Reverse the above steps for reassembly tasking
care to replace fixing glue.
3. To remove door parts.
2
3
1
5
4
6
Door Plate
3
2
1
NOTE : After replacing the door perform a check
of correct alignment with the hinge and
cavity front face.
