REF NO PART CODE PART NAME DESCRIPTION Q’TY REMARKS
A1 3517003820 BARRIER-SCREEN*0 PMMA T1.5 1
A2 3512203110 FRAME DOOR ABS H2938 HR-420 1
A3 3515202400 STOPPER HINGE *T AS KOR-41125J 1
A4 3511707200 DOOR WELD AS KOR-41125J 1
A5 3517003700 BARRIER-SCREEN *I POLYESTER T0.1 1
A6 3512300600 GASKET DOOR PP 1
A7 3513100810 HOOK POM 1
A8 3515101500 SPRING HOOK` SWP T0.7 1
1. Door Assembly
DOOR ASSEMBLY:3511707130
