18
8. To remove fan motor assembly.
(1) Remove screw ¤ from the rear panel of cavity. (2) Remove screw ¤ from the rear panel of cavity.
(3) Pull out the guide wind assembly. (4) Pull out the fan ¤ºfrom the fan motor ¤Ø.
(5) Remove two screws ¤Łfrom the fan motor ¤Ø. (6) Remove the fan motor ¤Øout of guide wind ¤Œ.
(7) Remove the filter ¤ out of guide wind ¤Œ. (8) Reverse the above steps for reassemble.
9. To remove transformer.
(1) Remove the four screw ¤ holding the H.V.
transformer ¤Ł.
(2) Remove the transformer ¤Ł.
(3) Reverse the above steps for reassembly.
CAUTION : Never install the magnetron without the metallic gasket plate which is packed with each magnetron
to prevent microwave leakage. Whenever repair work is carried out on magnetron, check the
microwave leakage. It shall nor exceed 4mW/cm2 for a fully assembled oven with door normally
closed.
