4. P.C.B. LOCATION NO.
No PART NAME REF NO. SPECIFICATION PART CODE Q
¡¡flfl
TY
1 RESISTOR R10, 12, 13, 18 4.7kΩ, 1/6W, 5% RD-AZ472J- 4
2 RESISTOR R3 200Ω, 1/6W, 5% RD-AZ201J- 1
3 RESISTOR R5, 8 20kΩ, 1/6W, 5% RD-AZ203J- 2
4 RESISTOR R1 1MΩ, 1/6W, 5% RD-AZ105J- 1
5 RESISTOR R2, 4, 6, 9, 15, 20 1kΩ, 1/6W, 5% RD-AZ102J- 5
6 RESISTOR R11, 17 47kΩ, 1/6W, 5% RD-AZ473J- 2
7 RESISTOR R6 1kΩ, 1/6W, 5% RD-AZ102J- 1
8 RESISTOR R24 51Ω, 1/4W, 5% RD-4Z510J- 1
9 RESISTOR R22, 25 56Ω, 1/2W, 5% RD-2Z560JS 2
10 RESISTOR R14, 19, 23 200Ω, 1/2W, 5% RD-2Z201JS 3
11 RESISTOR R21 1.2kΩ, 1/2W, 5% RD-2Z122JS 1
12 DIODE SWITCHING D1~D10 1N4148M(5mm) DZN4148M-- 10
13 DIODE RECTIFYING D11~D14 1N4002A AUTO 52mm DZN4002A-- 4
14 DIODE ZENER ZD1 MTZ3.9VB, 1/2W DZTZ3R9B-- 1
15 DIODE ZENER ZD2 5.1VB, 1/2W DZTZ5R1B-- 1
16 DIODE ZENER ZD3 20VB, 1/2W DZTZ20B--- 1
17 TRANSISTOR Q5 KTC3198GR (1815GR) TZTC3198GR 1
18 TRANSISTOR Q1~Q4 KTA1270Y(562Y) TZTA1270Y- 4
19 RESISTOR ARRAY RA1 7P(6) 100kΩ 1/8W J RA-87X104J 1
20 CAPACITOR CERAMIC C4 HIKF 50V 0.01µF Z CCXF1H103Z 1
21 CAPACITOR CERAMIC C1-3 HIKF 50V 0.1µF Z CBXF1H104Z 3
22 CAPACITOR ELECTROLYTIC EC5 220µF, 50V, RSS 10X16 CEXE1H221V 1
23 CAPACITOR ELECTROLYTIC EC1-2 47µF, 16V, RS 6.3X11 CEXE1C470A 2
24 CAPACITOR ELECTROLYTIC EC3 0.1µF, 50V, RS 5X11 CEXE1H108A 1
25 CAPACITOR ELECTROLYTIC EC4 2.2µF, 50V, RS 5X11 CEXE1H229A 1
26 CAPACITOR ARRAY CA1 1000pF, 2.54MM, M50V CN6XB-102M 1
27 BUZZER BZ1 BM-20K 3515600100 1
28 RESONATOR CR1 KBR-4.0MKSTF 5PKBR40MKS 1
29 CONNECTOR FILM CN2 FCZ 254-11 441M367160 1
30 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
31 CONNECTOR FILM CN1 YW396-02V 3519150520 1
32 DIGITRON DP1
SVM-5MS06 DSVM5MS06-
1
4TM-07ZB D4MT07ZB--
33 HOLDER VFD HD1 NYLON66 3513000500 1
34 BOARD PCB MAIN BORD M145-1 3514311351 1
35 TRANS POWER LVT DMR-604FS 5EPV041354 1
36 RELAY RY1, 3 G5J-1-TP-M24V 5SC0101107 2
37 RELAY RY2 G5B-1 (DC24V) 5SC0101109 1
38 IC MICOM IC1 HD404314B45S 147S611LP0 1
ƒJ) R12, D8, Q2, RY3 for Germany
