39
00001 9979800540 PCB MAIN T=1.6*246*247 (531X)
00002 9979800548 PCB CRT T=1.6*108*82(531X)
00020 W3475N731- CORD POWER 3 H05VV-F 3X0.75 1.8 IV
B001 5PB13890-- COIL BEAD BI3890
B006 5PB13890-- COIL BEAD BI3890
B007 5PB13890-- COIL BEAD BI3890
B101 5PB13857-- COIL BEAD BI3857(AXIAL)
B102 5PB13857-- COIL BEAD BI3857(AXIAL)
B501 5PB13857-- COIL BEAD BI3857(AXIAL)
B503 5PB13857-- COIL BEAD BI3857(AXIAL)
B801 5PB13857-- COIL BEAD BI3857(AXIAL)
B802 5PB13857-- COIL BEAD BI3857(AXIAL)
B803 5PB13857-- COIL BEAD BI3857(AXIAL)
B804 5PB13857-- COIL BEAD BI3857(AXIAL)
C001 CL1UC3104M C LINE ACROSS WORLD AC250V 0.1UF M R.47
C002 CEYP2G151Z C ELECTRO 400V SMH 150MF (25.4*40)
C003 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C005 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C007 CCXB2H103K C CERA HIKB 500V 0.01MF K
C008 CCXF1H104Z C CERA 50V F 0.1MF Z
C009 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C010 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C011 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C012 CMXM2A152J C MYLAR 100V 1500PF J (TP)
C013 CMXM2A272J C MYLAR 100V 2700PF J (TP)
C014 CCXB3A221K C CERA 1KV B 220PF K (TAPPING)
C015 CH1FDF472M C CERA AC 2.5KV 4700PF M AC250V
C016 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C101 CCXB3A331K C CERA 1KV B 330PF K (TAPPING)
C102 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C104 CEXF2A331V C ELECTRO 100V RSS 330MF (16X25) TP
C105 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C106 CCXF1H104Z C CERA 50V F 0.1MF Z
C107 CCXF1H104Z C CERA 50V F 0.1MF Z
C108 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C109 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C110 CCXF1H104Z C CERA 50V F 0.1MF Z
C111 CEXF1C471V C ELECTRO 16V RSS 470MF (10X12.5)TP
C112 CCXF1H104Z C CERA 50V F 0.1MF Z
C113 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C118 CCXF1H104Z C CERA 50V F 0.1MF Z
C201 CCXF1H104Z C CERA 50V F 0.1MF Z
C202 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C204 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C205 CCXF1H104Z C CERA 50V F 0.1MF Z
C208 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C209 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
ELECTRICAL PARTS LIST
The components identified by mark have special characteristics important for safety and x-ray
radiation. These should be replaced only with the types specified in the parts list.
LOC PART-CODE PART-NAME PART-DESC
C210 CCXB1H181K C CERA 50V B 180PF K (TAPPING)
C211 CCXB1H181K C CERA 50V B 180PF K (TAPPING)
C216 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C220 CCXF1H104Z C CERA 50V F 0.1MF Z
C224 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C225 CCXF1H104Z C CERA 50V F 0.1MF Z
C226 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C227 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C228 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C230 CCXB1H152K C CERA 50V B 1500PF K (TAPPING)
C231 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C233 CCXF1H104Z C CERA 50V F 0.1MF Z
C239 CCXF1H104Z C CERA 50V F 0.1MF Z
C240 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C401 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C402 CMXM2A154J C MYLAR 100V 0.15MF J (TP)
C409 CMXM2E104J C MYLAR 250V 0.1MF J
C410 CMXM2A272J C MYLAR 100V 2700PF J (TP)
C411 CEXF1V221V C ELECTRO 35V RSS 220MF (10X12.5)TP
C412 CMXL1J105J C MYLAR MEU 63V 1MF J
C413 CMXM2A562J C MYLAR 100V 5600PF J (TP)
C414 CEXF1C471V C ELECTRO 16V RSS 470MF (10X12.5)TP
C417 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C418 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C422 CCXB1H103K C CERA 50V B 0.01MF K
C423 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C504 CMXM2A223J C MYLAR 100V 0.022MF J TP
C505 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C506 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C507 CMXM2A562J C MYLAR 100V 5600PF J (TP)
C508 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C509 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C510 CMXM2A822J C MYLAR 100V 8200PF J (TP)
C512 CCXF1H104Z C CERA 50V F 0.1MF Z
C514 CEXF1C220V C ELECTRO RSS 16V 22MF 5*11
C515 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C516 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C517 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C519 CMYH3C472J C MYLAR 1.6KV BUP 4700PF J
C520 CMXE2J562J C MYLAR 630V PU 5600PF J (TP)
C521 CCXB1H271K C CERA 50V B 270PF K (TAPPING)
C522 CCXB2H331K C CERA 500V B 330PF K (TAPPING)
C524 CEXF2A331V C ELECTRO 100V RSS 330MF (16X25) TP
C527 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C528 CMYF2D564J C MYLAR 200V MPP 0.56MF J
C531 CMXF2D224J C MYLAR MPP 200V 0.22MF J
C532 CMYF2D684J C MYLAR 200V MPP 0.68MF J
LOC PART-CODE PART-NAME PART-DESC
!
!
!
