41
D612 DRGP10K--- DIODE RGP10K
D613 DRGP10K--- DIODE RGP10K
D801 DZN4148--- DIODE 1N4148 AUTO 52MM
D802 DZN4148--- DIODE 1N4148 AUTO 52MM
D803 DBAV20---- DIODE BAV20
D804 DBAV20---- DIODE BAV20
D831 DZN4148--- DIODE 1N4148 AUTO 52MM
D832 DZN4148--- DIODE 1N4148 AUTO 52MM
D833 DBAV20---- DIODE BAV20
D834 DBAV20---- DIODE BAV20
D861 DZN4148--- DIODE 1N4148 AUTO 52MM
D862 DZN4148--- DIODE 1N4148 AUTO 52MM
D863 DBAV20---- DIODE BAV20
D864 DBAV20---- DIODE BAV20
DG001 5MG0000066 COIL DEGAUSSING DG-526X
DL211 DSD50GYW-- LED SD50GYW(GREEN/AMBER)
DZ001 DDZ7R5BM-- DIODE ZENER DZ7.5BM
DZ003 DDZ22BM--- DIODE ZENER DZ22BM
DZ006 DDZ15BM--- DIODE ZENER DZ15BM
DZ201 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ202 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ203 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ205 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ206 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ207 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ208 DDZ5R1B--- DIODE ZENER DZ-5.1B
DZ212 DDZ5R1B--- DIODE ZENER DZ-5.1B
F001 5F3CB3122L FUSE CERA SEMKO TL 3.15AH 250V MF51
GND1 9970710233 CONN AS HOLDER+1015#18+SOLDER=100
GND2 9970710247 CONN AS 35068+35072+1015#22=160
GND3 9970710247 CONN AS 35068+35072+1015#22=160
IC001 1H3842P--- IC POWER H3842P
IC101 1UTC78L05M IC REGULATOR 78L05M
IC102 1KA78R12-- IC REGULATOR KA78R12
IC201 1DWM240T-- IC MICOM NT68P62
IC202 124C08---- IC EEPROM 24C08
IC204 1DW0SD11-- IC OSD NT6828-00005
IC401 1KA2142--- IC V-OUT KA2142
IC501 1TDA4856-- IC H.OSC TDA4856
IC801 1TDA9210-- IC VIDEO PREAMP TDA9210
IC802 1TDA9536-- IC VIDEO OUTPUT TDA9536
L502 5MH0000079 COIL H-LINEARITY TRL-531X
L503 5MC0000060 COIL CHOKE TCH-18A
L505 5MC0000060 COIL CHOKE TCH-18A
L801 5CPZ568K02 COIL PEAKING 0.56UH K (AXIAL 3.5MM)
L831 5CPZ338K02 COIL PEAKING 0.33UH K (AXIAL 3.5MM)
L861 5CPZ568K02 COIL PEAKING 0.56UH K (AXIAL 3.5MM)
P001 9979500024 RECEPTACLE 02ME4E3P/FILTER EMI
PR001 DECPAC140M POSISTOR ECPAC140M290
LOC PART-CODE PART-NAME PART-DESC
Q001 TSPP04N60S FET SPP04N60S5
Q002 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q101 TZTA1270Y- TR KTA1270Y(AUTO)(562Y)
Q102 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q105 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q204 TZSR1009-- TR KSR1009
Q401 TKSD471ACY TR KSD471ACY
Q501 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q504 TKSC2383Y- TR KSC 2383-Y
Q505 T2SC5387-- TR H.OUT 2SC5387
Q506 TZTC3197-- TR KTC3197 (AUTO)(388A)
Q507 T1RF630A-- FET IRF630A
Q510 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q511 T1RF630A-- FET IRF630A
Q512 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q513 T1RF630A-- FET IRF630A
Q515 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q516 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
Q517 TBD677A--- TR BD677A
Q560 T2N6520--- TR 2N6520
Q591 TZTA1270Y- TR KTA1270Y(AUTO)(562Y)
Q592 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q610 TZTC3198Y- TR KTC3198Y-(1815Y) (AUTO)
Q611 TKSP45---- TR KSP45
Q612 TKSP45---- TR KSP45
Q613 TKSP45---- TR KSP45
Q614 TKSP45---- TR KSP45
Q615 TZTA1266Y- TR KTA1266Y- (AUTO)(1015Y)
R003 RD-4Z105J- R CARBON FILM 1/4 1M OHM J
R004 RS02Z104J- R M-OXIDE FILM 2W 100K OHM J TAPPING
R005 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R006 RD-AZ564J- R CARBON FILM 1/6 560K OHM J
R007 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R008 RD-AZ242J- R CARBON FILM 1/6 2.4K OHM J
R009 RS01Z273J- R M-OXIDE FILM 1W 27K OHM J (TAPPING)
R012 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R013 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R014 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R015 RS01Z228J- R M-OXIDE FILM 1W 0.22 OHM J
R016 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R017 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R018 RD-AZ823J- R CARBON FILM 1/6 82K OHM J
R026 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R104 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R105 RD-4Z331J- R CARBON FILM 1/4 330 OHM J
R107 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R110 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R111 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R112 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
LOC PART-CODE PART-NAME PART-DESC
!
!
!
!
!
!
