10
EXPLODED VIEW AND PARTS LIST
No Parts Name Parts Code Description
Q'ty
211MC 311MC 511MC
1 PANEL FRONT 9CD0305400 MIPS 1 1 1
2 DOOR CASS. A/B
9CD1808900 MIPS 1 1 1
9CD1809000 MIPS 1 1 1
3 SPRING DOOR EJECT 9CD3004500 PW-1 1 1 1
4 SPRING C HOLD 9CD3003900 STS T0.2 1 1 1
5 DAMPER AS 9CD2602800 DA-12 1 1 1
6 DECK MECHANISM 9CD6006200 S/S , ADR2010FW2 1 1 1
7 DOOR CD 9CD1808800 MIPS 1 1 1
8 WINDOW FRONT 9CD1613400 ACRYL, BLACK 1 1 1
9 WINDOW FLT 9CD1613300 ACRYL, SMOG 1 1 1
10 WINDOW DOOR A/B
9CD1613100 ACRYL, VIOLET 1 1 1
9CD1613200 ACRYL, VIOLET 1 1 1
11 KNOB CD 9CD1332200 ABS 1 1 1
12 KNOB POWER 9CD1333700 ABS 1 1 1
13 KNOB CD A 9CD1333200 ABS 1 1 1
14 KNOB FUNCTION 9CD1333400 ABS 1 1 1
15 KNOB TIMER 9CD1333800 ABS 1 1 1
16 KNOB EQ 9CD1333300 ABS 1 1 1
17 KNOB VOLUME 9CD1333600 ABS 1 1 1
18 SHAFT VOL 9CD3601700 ACETAL 1 1 1
19 SHAFT ST 9CD3601800 ACETAL 1 1 1
20 KNOB DECK Auto/Play
9CD1333900 ABS 1 1 1
9CD1334000 ABS 1 1 1
21 BRKT SIDE 9CD2412900 ABS 2 2 2
22 BRKT PCB B 9CD2413200 SECC T1.0 2 2 2
23 CUSHION FOOT 9CD4207700 URETHAN FOAM RUBBER 2 2 2
24 COVER TOP 9CD0409600 MIPS 1 1 1
25 SPRING TUNING 9CD3007000 SUS 1 1 1
26 CD DECK MECHANISM 9CD6006100 3CD CH, S/S, W/O PCB ASSAY 1 1 1
27 COVER SIDE L/R
9CD0409200 MIPS 1 1 1
9CD0409300 MIPS 1 1 1
28 HEAT SINK 9CD4402800 BSP T0.5 1 1 1
29 CHASSIS BOTTOM 9CD0607100 SECC T1.0 1 1 1
30 BRKT PCB A 9CD2413100 SECC T1.0 1 1 1
31 HEAT SINK 9CD4404000 AL 30W --- --- ---
31-1 HEAT SINK 9CD4405000 AL 20W --- --- 1
31-2 HEAT SINK 9CD4404500 AL 10W --- 1 ---
31-3 HEAT SINK 05 9CD4405100 AL 5W 1 --- ---
32 HEAT SINK TR 9714403200 AL-EX 1 1 1
33 DECO FRONT 9CD1002300 ABS 1 1 1
34 COVER BACK 9CD0409400 MIPS 1 1 1
35 BADGE DAEWOO 9CD1500900 ABS, HOT STAMPING 1 1 1
36 GUIDE FLT 9CD2505600 ABS 1 1 1
37 HOLDER AC CORD 9CD2303300 ABS 1 1 1
38 BRKT H. SINK 9CD2413900 SUS 0.3 1 1 1
P1 PCB MAIN 1 1 1
P2 PCB FRONT 1 1 1
P3 PCB CD 1 1 1
P4 PCB POWER 1 1 1
P5 PCB TAPE
S1 SCREW TAPTTITE 7173300811 TT2 BIN 3.0X 8 MFZN 4 4 4
S2 SCREW TAPTTITE 7173301011 TT2 BIN 3.0X10 MFZN 23 23 23
S3 SCREW TAPTTITE 7173261011 TT2 BIN 2.6X10 MFZN 17 17 17
S4 SCREW TAPTTITE 7173301212 TT2 BIN 3X12 MFZN BK 25 25 25
S5 SCREW TAPTTITE 7173400611 TT2 BIN 4X6 MFZN 6 6 6
S6 SCREW TAPTTITE 7173300511 TT2 BIN 3X5 MFZN 1 1 1
S7 WASHER SCREW 9CD3102400 TT2 BIN 3X10 + D14 1 1 1
W WASHER I:3.2, O: 6.0 1 1 1
