CONN AS 9738835000 1 UL 2851 #28X2C0 3P 260MM CN603 CW603
CONN AS 9738835200 1 UL 2851 #28X3C0 5P 230MM CN602 CW602
CONN AS 9738835300 1 UL 1007 #26 1P 110MM W002
CONN AS 9738835400 1 UL 1007 #26 1P 260MM W003
CONN AS 9738840800 1 FFC 16P P1.0X250MM R CN501
CONN AS 9738840900 1 FFC 19P P1.25X110MM K CN508
CONN PIN 9736407800 1 53095-1010 10PIN ANGLE CN702
CONN WAFER 9CD6258800 1 2P S2B-XH-A CW101
CONN WAFER 9CD6259300 1 52807-1610 CW501
CONN WAFER 9CD6259400 1 2001-WS-12P CW507
CONN WAFER 9CD6259500 1 2001-WS-6P CW503
CONN WAFER 9CD6259600 1 2503-WS-2P CW502
CONN WAFER 9736407900 1 52084-1010 10P BOTTOM CW702
CONN WAFER 9736408300 1 52492-1920 19P BOTTOM CW703
CONN WAFER 9736408400 1 52045-1945 19P CW508
CORD AC 9736908100 1 SPT-2 18AWGX2C CD901
CRYSTAL
QUARTZ
5XA32R768- 1 DT-38 32.768KHZ 20PPM XC701
CRYSTAL
QUARTZ
5XA7R2000D 1
HC-18/U 7.200000MHZ
25PPM
XC251
DIODE DRL202---- 4 RL202 D904 D905 D906 D907
DIODE DZN4148--- 20 1N4148 AUTO 52MM
D201 D470 D471 D472 D473
D501 D502 D602 D604 D605
D606 D607 D608 D609 D610
D701 D702 D703 D810 JW211
DIODE D1N4001--- 4 1N4001 D901 D902 D911 D912
DIODE ZENER DZTZ3R9B-- 1 MTZ3.9B DZ502
DIODE ZENER DZTZ30B--- 1 MTZ30B DZ901
DIODE ZENER DZTZ5R6B-- 3 UZ-5.6B DZ501 DZ503 DZ504
DIODE ZENER DZTZ6R2B-- 3 MTZ6.2B DZ601 DZ602 DZ902
FET TKTK117Y-- 2 KTK117(Y) Q601 Q602
FILTER 5PPCFAZ077 1 PCFAZ077 CF201
FILTER CERA 5PE107MS3A 2 SFE107MS3-A CF001 CF002
FUSE GLASS
TUBE
5F1GB5012L 1
UL/CSA MF51 500MA 250V
TL
F901
IC 1BA1450S-- 1 BA1450S IC201
IC 1DBL2084-- 2 DBL2084(D/W) IC504 IC506
IC 1LC72130-- 1 LC72130 IC202
IC 1L4959---- 1 L4959 IC402
IC 1MC7805--- 1 MC 7805 (KA7805) IC205
IC 1M24C04--- 1 M24C04-BN6 IC705
IC 1M38199208 1 U-COM M38199 IC702
IC 1PNA4612HB 1 PNA4612M00HB IC704
IC 1TA8189N-- 1 TA8189N IC601
IC 1TDA7440D- 1 TDA7440D IC401
IC 1TDA7499-- 1 TDA7499 IC403
IC AUDIO 1KA9270--- 1 KA9270 IC505
IC AUDIO DSP 1KA9282B-- 1 KA9282B IC502
Parts Name Parts Code Q'ty Discription Location
IC CHIP 1KA9258D-- 1 KA9258D IC503
IC CHIP RF 1KA9220B-- 1 KA9220B IC501
IC SWITCHING 1BA7755A-- 1 BA7755A (HEAD SW) IC602
JACK HEAD-
PHONE
9766319501 1 HTJ-064-05B GOLD J801
JACK RCA 9CD6313700 1 S-436P J401
JACK SPEAKER 9736320500 1 CJ-9007-040 J802
PCB CD 9CD6574800 1 247X197 B501
PCB FRONT 9CD6576200 1 247X139X1.6T B001
PCB MAIN 9CD6576300 1 330X197X1.6T B001
PCB POWER 9CD6576301 1 105X78X1.6T B901
PIN WAFER 9736407700 1 52084-1310 13P BOTTOM CW701
PIN WRAPPING 9713550400 4 1.0X2.5X15 TP501 TP502 TP503 TP504
PIN WRAPPING 9716404000 2 MFZN1.1X1.1 PANASERT TP901 TP902
R CARBON FILM RD-AZ100J- 7 1/6 10 OHM J
R004 R009 R206 R255 R545
R726 R921
R CARBON FILM RD-AZ101J- 13 1/6 100 OHM J
R008 R102 R227 R228 R436
R437 R546 R657 R672 R686
R725 R748 R756
R CARBON FILM RD-AZ102J- 46 1/6 1K OHM J
R208 R215 R216 R251 R256
R260 R261 R262 R263 R409
R410 R423 R424 R431 R432
R442 R511 R521 R522 R563
R564 R580 R601 R602 R603
R604 R613 R614 R639 R640
R647 R648 R655 R659 R660
R665 R666 R758 R803 R804
R815 R816 R817 R818 R819
R820
R CARBON FILM RD-AZ103J- 30 1/6 10K OHM J
R205 R213 R214 R254 R257
R258 R579 R619 R620 R641
R662 R669 R674 R675 R680
R681 R682 R683 R685 R700
R705 R719 R720 R721 R750
R825 R910 R912 R913 R923
R CARBON FILM RD-AZ104J- 23 1/6 100K OHM J
R109 R421 R422 R425 R426
R433 R434 R435 R502 R510
R518 R519 R548 R549 R567
R568 R584 R585 R661 R722
R728 R729 R823
R CARBON FILM RD-AZ105J- 6 1/6 1M OHM J
R505 R508 R559 R560 R622
R684
R CARBON FILM RD-AZ106J- 1 1/6 10M OHM J R723
R CARBON FILM RD-AZ109J- 2 1/6 1 OHM J R939 R940
R CARBON FILM RD-AZ121J- 2 1/6 120 OHM J R003 R551
R CARBON FILM RD-AZ122J- 2 1/6 1.2K OHM J R405 R406
R CARBON FILM RD-AZ123J- 10 1/6 12K OHM J
R259 R509 R523 R531 R532
R533 R538 R539 R557 R558
R CARBON FILM RD-AZ124J- 1 1/6 120K OHM J R513
R CARBON FILM RD-AZ151J- 4 1/6 150 OHM J R627 R628 R747 R755
R CARBON FILM RD-AZ152J- 3 1/6 1.5K OHM J R740 R749 R757
R CARBON FILM RD-AZ153J- 9 1/6 15K OHM J
R403 R404 R411 R412 R515
R553 R554 R643 R644
R CARBON FILM RD-AZ154J- 3 1/6 150K OHM J R503 R525 R821
R CARBON FILM RD-AZ181J- 2 1/6 180 OHM J R746 R754
R CARBON FILM RD-AZ182J- 2 1/6 1.8K OHM J R413 R414
Parts Name Parts Code Q'ty Discription Location
ELECTRICAL PARTS LIST
