R CARBON FILM RD-AZ183J- 5 1/6 18K OHM J R201 R203 R526 R813 R814
R CARBON FILM RD-AZ184J- 7 1/6 180K OHM J
R504 R623 R625 R626 R637
R638 R651
R CARBON FILM RD-AZ220J- 2 1/6 22 OHM J JW117 R534
R CARBON FILM RD-AZ221J- 4 1/6 220 OHM J R003 R552 R933 R934
R CARBON FILM RD-AZ222J- 7 1/6 2.2K OHM J
R211 R212 R253 R264 R407
R408 R581
R CARBON FILM RD-AZ223J- 6 1/6 22K OHM J
R107 R528 R530 R615 R616
R911
R CARBON FILM RD-AZ224J- 2 1/6 220K OHM J R629 R630
R CARBON FILM RD-AZ271J- 4 1/6 270 OHM J R654 R745 R753 R759
R CARBON FILM RD-AZ272J- 6 1/6 2.7K OHM J
R222 R223 R611 R612 R617
R618
R CARBON FILM RD-AZ273J- 3 1/6 27K OHM J R542 R555 R556
R CARBON FILM RD-AZ331J- 5 1/6 330 OHM J R007 R441 R663 R744 R752
R CARBON FILM RD-AZ332J- 9 1/6 3.3K OHM J
R005 R106 R221 R415 R416
R516 R541 R543 R922
R CARBON FILM RD-AZ333J- 2 1/6 33K OHM J R621 R656
R CARBON FILM RD-AZ334J- 5 1/6 330K OHM J R650 R673 R724 R727 R730
R CARBON FILM RD-AZ391J- 3 1/6 390 OHM J R739 R743 R751
R CARBON FILM RD-AZ392J- 3 1/6 3.9K OHM J R529 R633 R634
R CARBON FILM RD-AZ393J- 5 1/6 39K OHM J R520 R537 R572 R586 R587
R CARBON FILM RD-AZ470J- 2 1/6 47 OHM J R209 R252
R CARBON FILM RD-AZ471J- 2 1/6 470 OHM J R738 R742
R CARBON FILM RD-AZ472J- 32 1/6 4.7K OHM J
R101 R103 R104 R105 R207
R210 R547 R561 R562 R565
R566 R573 R574 R575 R576
R577 R578 R582 R583 R642
R645 R646 R664 R667 R670
R671 R677 R678 R679 R708
R764 R765
R CARBON FILM RD-AZ473J- 8 1/6 47K OHM J
R439 R440 R512 R653 R658
R824 R914 R915
R CARBON FILM RD-AZ474J- 6 1/6 470K OHM J
R217 R218 R443 R444 R501
R540
R CARBON FILM RD-AZ479J- 1 1/6 4.7 OHM J R652
R CARBON FILM RD-AZ561J- 6 1/6 560 OHM J
R569 R570 R571 R668 R737
R741
R CARBON FILM RD-AZ562J- 3 1/6 5.6K OHM J R429 R430 R527
R CARBON FILM RD-AZ563J- 5 1/6 56K OHM J R514 R517 R624 R805 R806
R CARBON FILM RD-AZ681J- 1 1/6 680 OHM J R006
R CARBON FILM RD-AZ682J- 5 1/6 6.8K OHM J R219 R609 R610 R631 R632
R CARBON FILM RD-AZ683J- 4 1/6 68K OHM J R607 R608 R649 R706
R CARBON FILM RD-AZ820J- 3 1/6 82 OHM J R506 R605 R606
Parts Name Parts Code Q'ty Discription Location
R CARBON FILM RD-AZ821J- 5 1/6 820 OHM J R635 R636 R736 R807 R808
R CARBON FILM RD-AZ822J- 4 1/6 8.2K OHM J R401 R402 R507 R524
R CARBON FILM RD-AZ823J- 2 1/6 82K OHM J R535 R536
R CARBON FILM RD-2Y229J- 1 1/2 2.2 OHM J R550
R CARBON FILM RD-4Z100J- 6 1/4 10 OHM J
R588 R589 R809 R810 R811
R812
R FUSIBLE RF-2F478J- 2 1/2 0.47 OHM J RF901 RF902
R METAL FILM RN-2Y475J- 1 1/2 4.7M OHM J R901
R SEMI FIXED RV1417222- 1
1/10 2.2K OHM B V6EK-
PV1S
RV601
R SEMI FIXED RV6417223- 3 VM6CK-PV(1S) B 22K OHM RV201 RV501 RV502
RESONATOR 5PCSA8MTZ- 1 "CSA8MTZ, 8MHZ" XC702
RESONATOR
CERA
5PCSA16R93 1 CSA16.93MXZ04 XC501
SCREW TAPP-
TITE
7173301011 19 TT2 BIN 3X10 MFZN
00240 00270 00280 00290 00310
00340 00350 00360
SCREW TAPP-
TITE
7173301212 22 TT2 BIN 3X12 MFZN BK 00140 00150 00160 00180 00210
SW TACT 5S50101001 19 KPT-1105A 1C-1P
SW706 SW707 SW708 SW709 SW710
SW711 SW712 SW713 SW714 SW715
SW716 SW717 SW721 SW722 SW723
SW724 SW725 SW726 SW727
SW TACT 5S50101008 2 KPT-1105V 1C-1P SW718 SW719
TR TKRC107M-- 1
KRC107-M TAP-
PING(KSR1006)
Q701
TR TKSA928AY- 2 KSA928A-Y Q501 Q502
TR TKSC2331Y- 1 KSC2331Y Q503
TR TKSR1003-- 1 KSR1003 Q504
TR TZTA107M-- 1 KTA107M(AUTO) Q003
TR TZTA1266Y- 5 KTA1266Y- (AUTO)(1015Y) Q603 Q604 Q608 Q611 Q803
TR TZTA1273Y- 2 KTA1273Y(966Y) Q621 Q901
TR TZTA966--- 1 KTA966 Q622
TR TZTC3194Y- 1 KTC3194Y Q001
TR TZTC3198Y- 20 KTC3198Y-(1815Y) (AUTO)
Q201 Q202 Q505 Q605 Q606
Q607 Q609 Q610 Q612 Q613
Q614 Q615 Q616 Q617 Q618
Q619 Q620 Q801 Q802 Q804
TRANS POWER 5TPJ060798 1 "EI-60 100V 50,60HZ JIS" PT901
TUNER PACK 9737613000 1 KST-F501VJA TU001
VFD DSVA09MM10 1 SVA09MM10 FD701
WIRE JUMPER W581GY5095 2 AWG22 1/0.65 SN 5 AUTO RF903 RF904
WIRE JUMPER W581GY6095 3 AWG22 1/0.65 SN 6 AUTO D601 D913 R002
Parts Name Parts Code Q'ty Discription Location
ELECTRICAL PARTS LIST
