33
4. 308MCE
Parts Name Parts Code Discription Q'ty Location
AM RF UNIT 5LR0000826 RBW07VB-K5020 1 L101
ANT AM LOOP 9CD6810200 LOOP-7 1 AT101
ANT FM 9716805900 1.5M PIG TAIL BLK 1 AT001
C CERA CCXB1H101K 50V B 100PF K (TAPPING) 1 CC203
C CERA CCXB1H102K 50V B 1000PF K (TAPPING) 6
CC001 CC253 CC254 CC601 CC602
CC607
C CERA CCXB1H152K 50V B 1500PF K (TAPPING) 2 CC603 CC604
C CERA CCXB1H272K 50V B 2700PF K (TAPPING) 2 CC801 CC802
C CERA CCXB1H472K 50V B 4700PF K (TAPPING) 1 CC213
C CERA CCXB1H561K 50V B 560PF K (TAPPING) 2 CC210 CC211
C CERA CCXB1H682K 50V B 6800PF K (TAPPING) 1 CC204
C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) 20
CC002 CC004 CC102 CC201 CC205
CC206 CC207 CC209 CC251 CC252
CC257 CC501 CC502 CC503 CC507
CC515 CC521 CC529 CC535 CC536
C CERA CCXF1H104Z 50V F 0.1MF Z 20
CC005 CC006 CC101 CC202 CC403
CC504 CC505 CC506 CC511 CC512
CC513 CC526 CC527 CC537 CC544
CC701 CC704 CC711 CC717 CC926
C CERA CCXF1H223Z 50V F 0.022MF Z (TAPPING) 24
CC404 CC408 CC409 CC702 CC703
CC710 CC716 CC718 CC825 CC911
CC912 CC913 CC914 CC915 CC916
CC917 CC918 CC919 CC920 CC921
CC922 CC923 CC924 CC925
C CERA CCXF1H473Z 50V F 0.047MF Z (TAPPING) 5 CC103 CC212 CC509 CC522 CC528
C CERA CCZB1E102K 25V B 1000PF K (AXIAL) 3 CC520 CC533 CC534
C CERA CCZB1E151K 25V B 150PF K (AXIAL) 2 CC531 CC532
C CERA CCZB1E152K 25V B 1500PF K (AXIAL) 1 CC523
C CERA CCZB1E222K 25V B 2200PF K (AXIAL) 2 CC510 CC516
C CERA CCZB1E391K 25V B 390PF K (AXIAL) 1 CC508
C CERA CCZB1E472K 25V B 4700PF K (AXIAL) 3 CC518 CC542 CC543
C CERA CCZB1E682K 25V B 6800PF K (AXIAL) 1 CC514
C CERA CXCH1H101J 50V CH 100PF J (TAPPING) 5 CC401 CC402 CC405 CC406 CC563
C CERA CXCH1H120J 50V CH 12PF J (TAPPING) 1 CC104
C CERA CXCH1H150J 50V CH 15PF J (TAPPING) 1 CC712
C CERA CXCH1H180J 50V CH 18PF J (TAPPING) 1 CC713
C CERA CXCH1H330J 50V CH 33PF J (TAPPING) 4 CC255 CC256 CC714 CC715
C CERA CXCH1H331J 50V CH 330PF J (TAPPING) 2 CC605 CC606
C CERA CZCH1E609K CH 25V 6PF K AXIAL 1 CC519
C CERA CZCH1E809K CH 25V 8PF K AXL 52MM 1 CC517
C CERA CZCH1H270J CH 50V 27PF J AXL 52MM 2 CC524 CC525
C ELECTRO CEXE1C102A 16V RS 1000MF 13X20 1 CE515
C ELECTRO CEXF1A102V 10V RSS 1000MF (10X16) TP 1 CE705
C ELECTRO CEXF1C221V 16V RSS 220MF (8X11.5) TP 5 CE507 CE511 CE512 CE513 CE517
C ELECTRO CEXF1C470V 16V RSS 47MF (5X11) TP 11
CE001 CE203 CE601 CE602 CE605
CE608 CE611 CE612 CE620 CE621
CE622
C ELECTRO CEXF1E101V 25V RSS 100MF (6.3X11) TP 12
CE201 CE214 CE251 CE417 CE506
CE508 CE509 CE510 CE514 CE516
CE524 CE706
C ELECTRO CEXF1E221V 25V RSS 220MF (8X11.5) TP 2 CE102 CE213
C ELECTRO CEXF1E470V 25V RSS 47MF (5X11) TP 2 CE518 CE523
C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP 10
CE206 CE418 CE501 CE504 CE603
CE604 CE618 CE619 CE708 CE804
C ELECTRO CEXF1H109V 50V RSS 1MF (5X11) TP 15
CE205 CE207 CE208 CE209 CE210
CE211 CE613 CE614 CE615 CE616
CE702 CE801 CE802 CE803 CE805
C ELECTRO CEXF1H220V 50V RSS 22MF (5X11) TP 2 CE204 CE607
C ELECTRO CEXF1H228V 50V RSS 0.22MF (5X11) TP 1 CE212
C ELECTRO CEXF1H229V 50V RSS 2.2MF (5X11) TP 14
CE101 CE411 CE412 CE413 CE414
CE415 CE416 CE606 CE704 CE707
CE904 CE905 CE906 CE907
C ELECTRO CEXF1H339V 50V RSS 3.3MF (5X11) TP 3 CE202 CE609 CE610
C ELECTRO CEXF1H470V 50V RSS 47MF (6.3X11) TP 5 CE617 CE911 CE913 CE914 CE915
C ELECTRO CEXF1H478V 50V RSS 0.47MF (5X11) TP 11
CE401 CE402 CE403 CE404 CE405
CE406 CE407 CE408 CE502 CE503
CE505
C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP 4 CE519 CE520 CE521 CE522
C ELECTRO CEXF1V102V 35V RSS 1000MF (13X25) TP 1 CE903
C ELECTRO CEXF1V222V 35V RSS 2200MF 16X31.5 2 CE901 CE902
C MYLAR CMXM1H102J 50V 0.001MF J (TP) 6
CM601 CM602 CM605 CM606 CM607
CM608
C MYLAR CMXM1H103J 50V 0.01MF J (TP) 2 CM204 CM205
C MYLAR CMXM1H104J 50V 0.1MF J 6
CM405 CM406 CM407 CM408 CM801
CM802
C MYLAR CMXM1H122J 50V 0.0012MF J 2 CM505 CM506
C MYLAR CMXM1H152J 50V 1500PF J 2 CM615 CM616
C MYLAR CMXM1H153J 50V 0.015MF J (TP) 4 CM201 CM202 CM203 CM613
C MYLAR CMXM1H183J 50V 0.018MF J 3 CM503 CM603 CM604
C MYLAR CMXM1H223J 50V 0.022MF J 1 CM611
C MYLAR CMXM1H272J 50V 2700PF J 1 CM614
C MYLAR CMXM1H332J 50V 3300 PF J 1 CM612
C MYLAR CMXM1H333J 50V 0.033MF J (TP) 2 CM501 CM504
C MYLAR CMXM1H393J 50V 0.039MF J 2 CM609 CM610
C MYLAR CMXM1H473J 50V 0.047MF J 2 CM804 CM805
C MYLAR CMXM1H562J 50V 5600 PF J 4 CM206 CM207 CM409 CM410
C MYLAR CMXM1H683J 50V 0.068 MF J 1 CM502
CLIP FUSE 9734600700 FC-5N 2 FC901 FC902
COIL BIAS OSC 5L0503K643 SM-10F 5.04MH 1 L601
COIL CHOKE 5LC682K822 6.8MH 2 L204 L205
COIL DESCRIMI-
NATO
5107FBK473 7X7 BLK KSZ-73S 1 L203
COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM) 2 L001 L251
CONN AS 9736407600 PIN BASE 53095-1310 13P 1 CN701
CONN AS 9738824100 2P UL2468 400MM 1 CN503
CONN AS 9738832100 7P 200 P=2.5 BOARDIN 1 CN509 CW504
CONN AS 9738833900 #22 8P BOARD-IN 300MM 1 CN901 CW901
CONN AS 9738834700 UL 1007 #26 1P 110MM 1 W001
Parts Name Parts Code Discription Q'ty Location
ELECTRICAL PARTS LIST
