EXPLODED VIEW AND PARTS LIST
NO. PART NAME CODE NO. DESCRIPTION 208MC 308MC 508MC
1 WINDOW DOOR A 9CD1612500 ACRYL SMOG 1 1 1
2 WINDOW DOOR B 9CD1612600 ACRYL SMOG 1 1 1
3 DOOR CASS A 9CD1808500 MIPS 1 1 1
4 DOOR CASS B 9CD1808600 MIPS 1 1 1
5 SPRING DOOR EJECT 9CD3004500 PW-1 2 2 2
6 SPRING C HOLDER 9713008900 STS T0.2 4 4 4
7 WINDOW FLT 9CD1612700 ACRYL VIOLET 1 1 1
8 KNOB VOLUME 9CD1332800 ABS 1 1 1
9 SHAFT WASHER 9CD3601600 ACETAL 1 1 1
10 CUSHION FOOT 9CD4207700 URETHAN FOAM RUBBER 2 2 2
11 PANEL FRONT 9CD0305100 MIPS 1 1 1
12 BRKT SIDE 9CD2412900 ABS 1.5GR 2 2 2
13 DAMPER AS 9CD2602800 DA-12 1 1 1
14 SHAFT VR 9CD3601500 ACETAL 1 1 1
15 KNOB CD 9CD1332200 ACRYL --- 1 1
16 BADGE DAEWOO 9CD1500900 ABS HOT STAMPING 1 1 1
17 WINDOW FRONT 9CD1612800 ACRYL 1 1 1
17-1 KNOB EQ DUMMY 9CD1335500 ACRYL 1 1 1
18 KNOB FUNCTION 9CD1332300 ABS 1 1 1
19 KNOB POWER 9CD1332500 ABS 1 1 1
20 KNOB PRESET 9CD1332400 ABS 1 1 1
21 KNOB HI SPEED 9CD1332600 ABS 1 1 1
22 GUIDE FLT 9CD2505600 ABS 1 1 1
23 KNOB EQ 9CD1332700 ABS 1 1 1
24 KNOB DECK A 9CD1332900 ABS 1 1 1
25 KNOB DECK B 9CD1333000 ABS 1 1 1
26 DECK MECHANISM 9CD6006200 ADR 2010 FW2 (SAMSUNG) 1 1 1
27 DOOR CD 9CD1808700 MIPS 1 1 1
28 HEAT SINK 9CD4402800 BSP 0.5T 1 1 1
29 CD DECK MECHANISM 9CD6006100 3CD CH, S/S, W/O PCB ASSY 1 1 1
30 PLATE MAGNET 9CD0909300 --- --- 1
32 COVER TOP 9CD0409100 MIPS --- --- 1
32-1 COVER TOP 9CD0409600 MIPS 1 1 ---
33 COVER SIDE L 9CD0409200 MIPS 1 1 1
34 COVER SIDE R 9CD0409300 MIPS 1 1 1
35 CHASSIS BOTTOM 9CD0607100 SECC T1.0 1 1 1
36 BRKT PCB A 9CD2413100 SECC T1.0 --- --- 1
37 HEAT SINK TR 9CD4403200 BSP T1.0 --- 4 4
38 HEAT SINK 9CD4403700 AL - EX --- --- 1
38-1 HEAT SINK 9CD4403900 AL SHEET --- 1 ---
38-2 HEAT SINK 9CD4405100 AL SHEET 1 --- ---
39 HOLDER AC CODE 9CD2303300 ABS 4.0GR 1 1 1
40 COVER BACK 9CD0409400 MIPS 1 1 1
41 BRACKET ANT 9CD2411100 SCP-1 T0.8 BK SPRAY 1 1 ---
P1 PCB MAIN 1 1 1
P2 PCB FRONT 1 1 1
P3 PCB CD --- 1 1
P4 PCB POWER 1 1 1
S1 SCREW TAPTTITE 7173261011 TT2 BIN 2.6X10 MFZN 12 16 16
S2 SCREW TAPTTITE 7173301012 TT2 BIN 3.0X5 MFZN --- --- 1
S3 SCREW TAPTTITE 7173301212 TT2 BIN 3.0X10 MFZN 34 38 40
S4 SCREW TAPTTITE 7173400611 TT2 BIN 3.0X12 MFZN BK 5 5 5
S5 SCREW TAPTTITE 7173300611 TT2 BIN 4.0X6 MFZN 4 6 8
W1 WASHER SCREW 9CD3102400 TT2 BIN 3.0X10 + D14 1 1 1
