Daewoo AMI-716L - Page 7

716L/716R
816L/816R
816LS/816
LSR
WINDOW DOOR A 9CD1613900 ACRYL 1 1
WINDOW DOOR B 9CD1614000 ACRYL 1 1
COVER DOOR A 9CD0410200 MIPS 1 1
COVER DOOR B 9CD0410300 MIPS 1 1
DOOR FRAME A/B 9CD1809400 MIPS 1 1
DOOR FRAME A/B 9CD1809500 MIPS 1 1
4 SPRING DOOR EJECT L 9CD30078L0 STS 1 1
5 SPRING DOOR EJECT R 9CD30078R0 STS 1 1
6 CUSHION FOOT 9CD4207700 URETHAN FOAM RUBBER 2 2
7 KNOB VOLUME 9CD1334400 ABS 1 1
8 DAMPER ASSY 9CDM029800 2 2
9 LOCKER ASSY 9CDM029900 2 2
10 WINDOW FLT 9CD1614100 ACRYL 1 1
11 KNOB EQ L 9CD1335300 ABS 1 1
12 KNOB EQ R 9CD1335400 ABS 1 1
13 BRKT SIDE 9CD2412900 ABS 2 2
14 PANEL FRONT 9CD0306000 MIPS 1 1
15 PLATE FLT 9CD0909800 PVC SHEET (T = 1.0) 2 -
16 BADGE DAEWOO 9CD1500900 ABS 1 1
17 PLATE FUNCTION 9CD0910000 PVC SHEET (T = 1.0) 1 1
18 DOOR CD 9CD1809300 MIPS 1 1
19 HEAT SINK 9CD4402800 BSP 1 1
20 CD MECHANISM 9CD6006900 1 1
21 COVER TOP 9CD0409600 MIPS 1 -
21-1 COVER TOP 9CD0409100 MIPS - 1
22 DECO TOP 9CD1002200 ACRYL - 1
23 WINDOW TOP 9CD1612900 PC SHEET - 1
24 CASS. DECK (A/S) 9CD6006800 1 -
24-1 CASS. DECK (A/R) 9CD6007000 - 1
25 PLATE SHIELD 9CD0908500 ALP - 1
26 KNOB FUNCTION 9CD1335100 ACRYL 1 1
27 PLATE FILTER 9CD0909900 PC SHEET (T=0.2) 1 1
28 KNOB CD PLAY 9CD1335700 ABS 1 1
29 KNOB PLAY MODE 9CD1335800 ABS 1 1
30 KNOB CONTROL 9CD1335000 ABS 1 1
31 GUIDE LED 9CD2506000 HIPS - 1
32 GUIDE FLT 9CD2505600 ABS 1 -
32-1 GUIDE FLT 9CD2505800 ABS - 1
33 COVER SIDE L 9CD0409200 MIPS 1 1
34 COVER SIDE R 9CD0409300 MIPS 1 1
35 CHASSIS BOTTOM 9CD0607500 MIPS - -
35-1 CHASSIS BOTTOM 9CD0607100 SECC (T=1.0) 1 1
36 HEAT SINK1 9CD4404500 AL - -
36-1 HEAT SINK3 9CD4404600 AL 1 -
36-2 HEAT SINK5 9CD4404700 AL - 1
37 BRKT HEAT TR 9CD2413900 STS - -
38 RUBBER SILICON 9CD4207900 RUBBER 1 -
39 COVER BACK 9CD0409801 MIPS 1 1
S1 SCREW TT2 BIN 2.6X10 13 13
S2 SCREW TT2 BIN 3X10 32 35
S3 SCREW WASHER TT2 BIN 3X10 1 1
S4 SCREW TT2 BIN 3X12 BK 5 5
S5 SCREW TT2 BIN 4X6 8 4
S6 SCREW TT2 BIN 2X4 - 2
P1 PCB Ass'y FRONT PCB - -
P1-1 PCB Ass'y FRONT PCB 1 -
P1-2 PCB Ass'y FRONT PCB - 1
P2 PCB Ass'y MAIN PCB -
P2-1 PCB Ass'y MAIN PCB 1
P2-2 PCB Ass'y MAIN PCB - 1
P3 PCB Ass'y POWER PCB - -
P3-1 PCB Ass'y POWER PCB 1 -
P3-2 PCB Ass'y POWER PCB - 1
P4 PCB Ass'y PCB CD LED ASS'Y - 1
Q'ty
1
3
2
No. Parts Name Parts Code Description
