Daewoo B25S-2 User Manual

Power Train Disassembly & Assembly
3. Install shaft assembly (8) in the housing.
4. Put Loctite No.242 Thread Sealant on th threads
of the bolts that hold the spindle.
5. Put spindle (7) in position, and install bolts (6) that
hold it. Tighten the bolts to a torque of 115 L 14
NIm (85 L 10 lbIft).
6. Install bearing (5) on the spindle.
7. Put hub and cover assembly (4) in position on the
housing, and install the bolts that hold it. Tighten
the bolts to a torque of 55 L 10 NIm (41 L 7 lbIft).
8. Install bearing (2) locking washer (1) and nut (3)
on the spindle.
9. With tool (A), tighten nut (3) slowly to 135 NIm
(100 lbIft) while the hub is turned to put the
bearings in position.
10. Loosen nut (3) completely, and tighten it again to
a torque of 50 L 5 NIm (37 L 4 lbIft).
11. Bend one of the tabs in washer (1) to hold the nut
in position.
End By:
a. Install brakes.
47
2
3
4
1
6
8
7
5
